Ballast Lampu Philips HF-S 236 TL-D II 220-240V adalah trafo atau ballast electronic HF-Selectalume II for TL-D lamps – PHILIPS HF-S 218/236 TL-D II 220-240V 50/60Hz untuk lampu fluorescent lamp Philips TL 2 x 36 watt yang dipakai untuk lampu proyek perkantoran yang menghasilkan 30% lebih hemat di banding dengan mengunakan ballast biasa, sangat efisien, sederhana, tidak membawa dampak terhadap umur lampu serta mendukung proses start dan operasi pada lampu.
Ballast Electronic HF-Selectalume II for TL-D lamps Philips dapat dipasangkan pada :
– Lampu TL T8 218/236 watt Philips / Osram
– Kap lampu seperti RM, Balok, TKO, TKI, Kap lampu Waterproof, dll, dan tidak memerlukan starter lagi setelah menggunakan ballast ini
Sangat cocok di gunakan untuk industri, garment, perkantoran, migas, mall, rumah sakit, dsb, yang memerlukan penerangan terus-menerus dengan pencahayaan konstant.
Langsung menyala ( Rapid Start ), tanpa bunyi dengung, kedip dan tidak memerlukan starter, dan kualitas cahaya yang konstan, menggunakan frekwensi tinggi
Specifications
General Information
– Application Code : II
– Type Version : mk1
– Lamp Type : TL-D
– Number Of Lamps : 2 piece/unit
– Number Of Products On MCB (16A Type B) (Nom) : 28
– Automatic Restart : Yes
Operating and Electrical
– Input Voltage : 220 to 240 V
– Input Frequency : 50 to 60 Hz
– Operating Frequency (Nom) : 45 kHz
– Crestfactor (Nom) : 1.7
– Power Factor 100% Load (Nom) : 0.98
– Preheat Time : 1.6 s
– Mains Voltage Performance (AC) : 202-254V-8%-+6%
– Mains Voltage Safety (AC) : 198-264V-10%-+10%
– Earth Leakage Current (Max) : 0.5 mA
– Inrush Current Width : 0.35 ms
– Ballast Factor (Nom) : 1.01
– Power Losses (Nom) : 4.6 W
– Inrush Current Peak (Max) : 18 A
Wiring
– Connector Type Input Terminals : WAGO 744 connector
– Cable Capacity Output Wires Mutual (Max) : 200 pF
– Connector Type Output Terminals : WAGO 744 connector [ Suitable for manual wiring]
– Cable Length Hot Wiring : 0.75 m
– Wire Striplength : 8.0-9.0 mm
– Dual Fixture Master/Slave : Possible, lamp wires 2m max. length [ Master/Slave operation possible]
– Input Terminal Cross Section : 0.50-1.50 mm²
– Output Terminal Cross Section : 0.50-1.50 mm²
– Cable Capacity Cold Output Wires – Earth (Max) : 200 pF
– Cable Capacity Hot Output Wires – Earth (Max) : 200 pF
System characteristics
– Rated Ballast-Lamp Power : 36/18 W
– Rated Lamp Power On TL-D : 36/18 W
– System Power On TL-D : 70.4/37.7 W
– Lamp Power On TL-D : 63.9/32.9 W
– Power Loss On TL-D : 6.5/4.8 W
– Rated Lamp Power On PL-L : 36 W
– System Power On PL-L : 66.7 W
– Lamp Power On PL-L : 61.2 W
– Power Loss On PL-L : 5.5 W
Temperature
– T-Ambient (Max) : 55 °C
– T-Ambient (Min) : -20 °C
– T-Storage (Max) : 80 °C
– T-Storage (Min) : -40 °C
– T-Case Lifetime (Nom) : 75 °C
– T-Case Maximum (Max) : 75 °C
Mechanical and Housing
– Housing : L 280x30x28
Emergency Operation
– Nominal Light Output After 60 Seconds : 100% of EBLF
– Normal Operating Voltage (DC) : 220-240 V
– Battery Voltage Guaranteed Operation : 176-275 V
– Battery Voltage Guaranteed Ignition : 186-275 V
– Emergency Ballast Lumen Factor (EBLF) (Nom) : 0.7 %
– Nominal Light Output After 5 Seconds : 50% of EBLF
Approval and Application
– Energy Efficiency Index : A2 BAT
– EMI 9 kHz … 30 MHz : EN55015
– Vibration Standard : IEC68-2-6 F c
– Bumps Standard : IEC 68-2-29 Eb (10G/16ms)
Product Data
– Full product code : 872790090553300
– Order product name : HF-S 218/236 TL-D II 220-240V 50/60Hz
– EAN/UPC – Product : 8711500999313
– Order code : 913713032466
– Numerator – Quantity Per Pack : 1
– Numerator – Packs per outer box : 12
– Material Nr. (12NC) : 913713032466
– Net Weight (Piece) : 0.193 kg
